CNC machining for glass ceramics

We have specialized for decades in the processing of special materials, most notably glass ceramics.

MACOR®

When it comes to machining glass ceramics, we trust one material above all others: Macor®. Macor® combines the performance of a technical ceramic material with the versatility of a high-performance polymer, making it extremely easy to work. With this material CNC turning and CNC milling using conventional tools and CNC machines can be used to manufacture even the most complex of molded parts and the smallest precision parts. If you need the performance of a technical ceramic material in pieces with a complex shape, Macor® glass ceramics are perfect for you.

This machining process facilitates flexible, geometrically accurate manufacturing without the need for afterburning. This significantly reduces the time between development and application and cuts down on costs.

High technical standards

Our plants are designed to enable highly efficient manufacturing for Macor® components that need to meet high standards of technical quality.

Did you know?

Did you know?

  • The working temperature of Macor® for continuous operation is 800°C, with peaks of 1,000°C.

  • It can achieve machining tolerances of up to 0.01 mm and a surface quality of less than Ra 0.1.

  • The material has low thermal conductivity, and remains a good thermal insulator even at high temperatures.

  • It is an excellent electrical insulator, and has been used successfully in the electronics and semiconductor industry.

  • Non-porous: It does not emit any gases when thoroughly heated in the furnace, making it the perfect material for ultra-high-vacuum applications.

  • High strength and rigidity.

  • Unlike high-temperature plastics, the material does not creep or warp.

  • The material is radiation-resistant, which has also made it popular in nuclear and aerospace applications.

  • It can be metallized in thin or thick layers, brazed, and bonded using epoxy resin or frits.

  • It is non-wetting, has zero porosity and, unlike ductile materials, does not warp.
MACOR® in detail

MACOR® in detail

Electrotechnical properties

  • High dielectric strength
  • High specific resistance
  • Low dissipation factor

Thermal properties

  • High working temperature
  • Moderate heat conductivity
  • High thermal expansion coefficient, can be bonded with ordinary glass

Chemical properties

  • Zero water absorption
  • Good chemical resistance
  • Is not wetted by molten aluminum, magnesium or tin

Stability

  • High stability
  • High scratch resistance
  • Dimensional stability
  • Isotropic and uniform
  • 50% higher impact resistance than Pyrex or Pyroceram

Vacuum impregnation

  • Zero porosity
  • No outgassing
  • Low helium penetration
  • Can be hermetically bonded with metals, ceramic materials and glass using solder glass

Metallization properties

  • Through vaporization of different metals
  • Can be sealed and coated
  • Hermetic sealing through the use of glass solder
  • Soldered seals on metallized parts
Top customer benefits

Top customer benefits

  • Cost-effective machining
  • Can be used to create highly complex shapes
  • Resistant to radiation
  • Low thermal conductivity
  • Very high working temperature
  • Good electrical insulator
  • Non-porous; no outgassing
  • Short lead times
  • No glost firing required

Get in touch with us – we’d love to help you out!

Contact

Downloads

You can find more information in our Macor® brochure.

Download brochure


MACOR® and Photoveel® processing

Photoveel N® – The high-performance ceramic material

In addition to Macor®, we can also machine the extremely hard ceramic material Photoveel N®, which has an incredibly high bending strength, with the utmost precision. We do this using our own in-house production process and our years of expertise with the product and in this field.

Thanks to its hardness and bending strength, Photoveel N® offers enormous advantages, especially in the fields of high vacuum, aerospace and nuclear technology.


Top MACOR® glass ceramics references


Other special materials

We are the perfect expert partner when it comes to machine-cutting tricky materials. Whether you require conventional materials or special materials such as tantalum, molybdenum, cobalt, pure silver, tungsten or Inconel, it’s no problem for us. Our cutting-edge CNC machines and highly qualified employees can manufacture complex components with the utmost precision.
